Description Product advantages Meets the requirements of IEC 62852 TÜV certification according to IEC 62852 in combination with corresponding PV cables UL certification according to UL 6703 in combination with corresponding PV cables Can also be used in systems outside the photovoltaic sector Product features Stäubli MC4-EVO 2 plug 4-6 mm² Cable cross-section (conductor): 4-6 mm² Outer cable diameter: 6.4 – 8.4 mm Rated voltage: 1,500 V DC Rated current with 4-6 mm² cable cross-section: 69 A Ambient temperature: -40 °C to 85 °C Protection category when plugged in: IP 65
