Description Geometry – Wheelbase: 920mm (measured with Link fork) – Chainstay: 337mm – BB Height: 15mm – Head Angle: 74˚ Specification – Seatpost: 27.2mm – Seatclamp: 31.8mm – BB shell: 73mm – Tyre clearance: 22 x 2.4″ – Headtube: Tapered (1-1/8″ Integrated Upper, 1.5″ Integrated Lower) – Dropouts: 12mm bolt through, 135mm spacing – Chainline: 51mm (Recommended minimum with 22T chainring) – Disc Mount: 20mm Post Mount (Designed to run a maximum rotor size of 185mm, using a larger rotor will void the warranty) Documentation 15mm Fork Axle Assembly Instructions (0.6MB) 12mm Frame Axle Assembly Instructions (0.6MB) Single Sided Tensioner Instructions (1.1MB) Additional Information Ensure axles are clean and there are no signs of damage before fitting. Make sure to apply a generous amount of good quality grease to all surfaces. Failure to fit the axles without following the approved process as outlined in the Axle Assembly Instruction document is likely to invalidate the warranty.
