Hikvision DS-1LN6UZC0 Cat6 Solid Copper Cable — Blue 305m Pull Box 24AWG solid bare copper · Cat6 U/UTP · Blue · 305m · ANSI/TIA-568.2-D · ISO/IEC11801 · RoHS 2.0 · Fluke certified · 57V PoE rated · Authorised Australian distributionThe Hikvision DS-1LN6UZC0 Cat6 solid copper cable is built on 24AWG solid bare copper conductors — 99.95% copper purity — delivering lower DC resistance, better signal integrity, and reliable power delivery on PoE camera runs up to 100 metres. CCA (copper-clad aluminium) cable looks identical on the reel but has significantly higher resistance, causing voltage drop on longer runs that results in cameras dropping offline, failing to power on, or performing erratically. The Hikvision DS-1LN6UZC0 Cat6 solid copper construction eliminates that risk entirely, and every box is sourced through authorised Australian distribution with full manufacturer warranty.Fluke Certified — Tested Under Real PoE LoadThe Hikvision DS-1LN6UZC0 Cat6 solid copper cable passes the Fluke 90-metre permanent link test while operating continuously at 50°C, and passes the Fluke 100-metre channel test while carrying a sustained 57V/1A DC PoE load simultaneously. That is the test that matters for IP camera installations — data and power delivery running concurrently, under heat, at full channel length. The result is a cable you can install with confidence that the performance figures reflect real-world conditions on every job.Built for Structured Cabling — Blue Pull Box, PVC Jacket, HDPE InsulationThe Hikvision DS-1LN6UZC0 Cat6 solid copper cable comes in a 305-metre blue pull box designed for professional installation — feed cable cleanly without tangling, kinking, or re-spooling across large floor plates, ceiling spaces, or multi-floor structured cabling runs. The blue PVC outer sheath provides strong mechanical protection against tensile and compressive forces during installation, maintaining integrity under the physical stress of pulling through conduit or across cable trays. HDPE insulation on each conductor maintains consistent 100Ω impedance across the full 250MHz bandwidth. Rip cord and pair separator are included as standard.PoE Reliability and Standards ComplianceWith a 57V operating voltage rating and DC resistance of ≤9.38Ω/100m, the Hikvision DS-1LN6UZC0 Cat6 solid copper cable is compatible with 802.3af (PoE), 802.3at (PoE ), and 802.3bt (PoE ) powered devices — including Hikvision IP cameras, NVR PoE ports, wireless access points, and VoIP phones. Compliant with ANSI/TIA-568.2-D, ISO/IEC11801, IEC61156, and RoHS 2.0 — the international standards required for sign-off on commercial cabling installations.SpecificationDetailModelDS-1LN6UZC0Cable TypeU/UTP Cat6Length305 metres (±1.5m)Conductor MaterialSolid bare copper (99.95%)Conductor Diameter0.50 ± 0.01mm (24AWG)Insulation MaterialHDPE (0.88 ± 0.05mm)Jacket MaterialPVC (5.30 ± 0.50mm OD)Jacket ColourBlueDC Resistance≤ 9.38 Ω/100mImpedance100 ± 15 Ω (1.0–250.0 MHz)Operating Voltage57VOperating Temperature-20°C to 70°CFire ResistanceNot ratedRip Cord / SeparatorYes / YesStandardsANSI/TIA-568.2-D · ISO/IEC11801 · IEC61156 · RoHS 2.0Package Dimensions390mm × 390mm × 210mmWeight9.9 ± 0.5 kgWhere the Hikvision DS-1LN6UZC0 Cat6 Solid Copper Cable Earns Its Place�� IP CCTV and NVR installations — Every run from a Hikvision NVR PoE port to an IP camera depends on the cable carrying data and power reliably over the same pair. The Hikvision DS-1LN6UZC0 Cat6 solid copper construction delivers consistent PoE voltage across the full 100-metre channel, eliminating the drop-outs and power failures that CCA cable produces on longer runs. One 305m box covers most residential and small commercial camera deployments end to end.�� Commercial structured cabling — Data, voice, and access control infrastructure in offices, retail, and commercial buildings. The Hikvision DS-1LN6UZC0 Cat6 solid copper cable meets ANSI/TIA-568.2-D for sign-off by structured cabling contractors and building services engineers. The blue pull box colour-codes the horizontal cabling layer cleanly against patch leads and other cable types on site.�� Wireless access points and networking — 802.3at and 802.3bt PoE access points draw sustained current across the full cable run. The Hikvision DS-1LN6UZC0 Cat6 solid copper construction handles the load without resistance-related voltage sag, keeping access points online at full transmit power.⚡ Electricians and security installers — A single 305m box of Hikvision DS-1LN6UZC0 Cat6 solid copper cable handles most residential and small commercial jobs end to end. Fluke certification means you can provide test documentation at handover, and the solid copper spec protects against callbacks from cameras dropping offline months after installation.FeatureDS-1LN6UZC0 Solid CopperGeneric CCA Cat6ConductorSolid bare copper 99.95%Aluminium core, copper coatingDC resistance≤ 9.38 Ω/100mSignificantly higherPoE on long runs✓ Consistent voltage to 100m✗ Voltage drop riskFluke certified✓ 90m link 100m channelOften uncertifiedStandards✓ ANSI/TIA · ISO/IEC · RoHS 2.0Often non-compliantAuthorised AU distribution✓ Full manufacturer warranty✗ Typically noneFrequently Asked Questions — Hikvision DS-1LN6UZC0 Cat6 Solid Copper CableQ: What is the difference between solid copper and CCA Cat6 for PoE cameras? Solid copper has lower electrical resistance than CCA (copper-clad aluminium), meaning less voltage drop over distance. For PoE cameras — particularly on runs over 40–50 metres — CCA cable can cause insufficient voltage at the camera end, leading to intermittent power failures or cameras refusing to power on. The Hikvision DS-1LN6UZC0 Cat6 solid copper construction eliminates this issue across the full 100-metre channel. CCA cable looks identical externally — the difference only becomes apparent under load, often months after installation.Q: Is the Hikvision DS-1LN6UZC0 Cat6 solid copper cable suitable for PoE and PoE devices? Yes. Rated to 57V operating voltage with DC resistance of ≤9.38Ω/100m, the DS-1LN6UZC0 is compatible with 802.3af (15.4W), 802.3at PoE (30W), and 802.3bt PoE (up to 90W) devices including Hikvision ColorVu and Smart Hybrid Light cameras, high-power wireless access points, and PoE switches. The Fluke 100-metre channel test was conducted with a sustained 57V/1A DC PoE load applied simultaneously with data transmission.Q: Will one 305m box be enough for my installation? For most residential and small commercial installs, one box of Hikvision DS-1LN6UZC0 Cat6 solid copper cable is generally sufficient. As a rough guide, 305m covers around 6 camera positions at 50m each or 10 positions at 30m each. However, cable runs are never straight-line distances — every run travels up walls, across ceiling spaces, around obstacles, and back down to the camera position, so real-world runs are always longer than a floor plan suggests. A qualified installer or electrician will measure actual run lengths before ordering. Allow additional cable for waste, termination tails, and any reruns.Build a Complete Hikvision CCTV SystemThe Hikvision DS-1LN6UZC0 Cat6 solid copper cable is the infrastructure behind every reliable Hikvision installation. Pair it with the Hikvision IP camera range and a Hikvision PoE NVR for a single-cable data and power run to each camera. Add Hikvision junction boxes for weatherproof cable entry at each camera position. Integrate a Hikvision AX Pro wireless alarm for alarm-triggered camera recording via Hik-Connect.The Hikvision DS-1LN6UZC0 Cat6 solid copper cable is part of the Hikvision structured cabling range at Comms Direct — sourced through authorised Australian distribution with full manufacturer warranty. Ships fast from Australian warehouses.For warranty enquiries or pre-purchase technical advice, contact us via the enquiry form or chat with us online.
